How to Choose the Right LED Skirting Board Height

The correct selection of LED skirting board height determines the aesthetic quality and visual harmony of a space. The selection of improper height can result in unsatisfactory lighting performance and unbalanced room appearance and installation difficulties. The following guide provides guidance for selecting optimal LED skirting board heights by analyzing typical dimensions alongside installation aspects and addressing common questions.

Common LED Skirting Board Height Ranges Explained

LED skirting boards require individual selection based on project needs since no universal height exists. Here's a breakdown:

Standard/Conventional Heights (60mm - 100mm):The versatile nature of these products works for most residential and office settings to produce a minimalist lighting effect. These installation methods work well for standard LED strips but the system might not provide adequate light diffusion when used in large areas. These fixtures work well in bedrooms and hallways and commercial corridors with ceiling heights ranging between 2.1m-2.4m.
Medium Heights (100mm - 150mm):The modern lighting market prefers these products because they generate better ambient light effects. The 2.4m to 2.7m ceiling range makes these fixtures suitable for living rooms and hotels when seeking to achieve a balance between visibility and aesthetic appeal. The benefits include stronger visual effects but the system requires additional wiring support.
Tall Heights (150mm and Above):The optimal choice for grand spaces including lobbies and period homes extends above 2.7m ceiling heights. These lighting fixtures create impressive lighting effects and height perception but their tall design might create an unbalanced appearance in smaller rooms. The system functions as a powerful visual anchor but requires complex installation methods and possible additional structural support.

When determining the suitable LED skirting board height use the 1/18th rule which means a 2.7m ceiling requires a 150mm installation.

Factors Affecting LED Skirting Board Height Choice

The following factors determine the most suitable LED skirting board height:

Ceiling Height:The height of skirting boards should be shorter than 145mm for ceilings below 2.4m and taller than 270mm for ceilings above 3m.
Aesthetic Preferences:Minimalist styles use slender profiles (40mm-70mm) while modern designs choose 100mm-150mm and traditional designs select 170mm+ for ornate details. The color choice of the walls can make them appear longer and horizontal lines become more prominent when contrasting colors are used.
Primary Function:A taller height (100mm+) is best for ambient lighting since it provides soft light diffusion but accent and task lighting work with shorter options (70mm-95mm) for precise effects. The height of flooring materials affects how much of the skirting board remains visible since thick carpets conceal 10mm to 20mm of the board.

Height-Related Installation Considerations for LED Skirting Boards

Wiring and Power:Strategic placement of drivers together with extended cables and 8-12mm wide grooves for LED strips becomes necessary when using taller boards. The wiring needs to be completely hidden to preserve the visual appeal.
Wall Flatness:Higher profiles need to be mounted on smooth walls since gaps can occur otherwise and adhesives or screws provide necessary stability.
Additional Support:Ultra-tall units reaching 150mm and higher require brackets as an essential installation in high-traffic locations. Measure the walls accurately before installing LED strips for testing purposes.
